EN_RU6104_Desktop_Reader

A larger HF desktop RFID reader-writer with anti-metal design for stable workstation use.

HF 13.56 MHz operation with ISO15693 and ISO18000-3 support.

Anti-metal design supports stable reading in desktop workstation scenarios.

Supports host-control and scanning modes configurable by software.

Integrated reader support for ISO15693 and ISO14443A card interaction.

Product Parameters

Product model	RU6104
Product name	HF Medium-Power Desktop Reader-Writer
Working frequency	13.56 MHz
Supported standards	ISO15693 and ISO18000-3
Reading speed	<= 50 tags per second
Reading distance	Up to 42 cm
Working mode	Host control and scanning, configurable by software
Adjacent read range	<= 5 cm
Energy saving	Automatic RF shutdown while idle
Anti-metal design	Yes
Reader support	ISO15693 and ISO14443A
Prompt sound	Buzzer, when enabled
RF power	0.25-1.5 W configurable

Physical & Environmental

Housing material	Tempered-glass panel, aluminum alloy
Noise detection	Supported
Waterproof	Not supported
Communication interface	RS232, USB
Operating temperature	-20 C to 60 C
Storage temperature	-40 C to 85 C
Maximum power consumption	3.5 W
Power input	12 V DC
Relative humidity	10%-95% RH, non-condensing
Anti-collision processing	Supported
Physical size	476 x 311.5 x 29 mm
Package size	545 x 385 x 65 mm
Gross weight	Approx. 3500 g

Mechanical Dimensions (mm)

RU6104
